EN10219 EN10218 Seamless Steel Pipe


Our mill supply EN10219 smls Steel Pipes,Hot-Rolled Steel Pipes(SMLS),EN10219 Hot Rolled Carbon Steel Pipes,EN10208 hot rolled seamless steel pipe,We been exported our steel pipes to overseas distributors,warehouses,and factories in USA,Europe,Thailand,Poland,Italy,Bangladesh,Mexico,Brazil,Peru,our professional technician team and high quality products improve our long-term business network.

EN10219 smls Steel Pipes

EN10219 Hot Rolled Steel Pipes Specification Range:
OD: 1/4"—28"
WT: 2mm-60mm
Executive standards:EN10219
Application: Hot Rolled Steel Pipes for low and medium pressure boiler,high pressure boiler,ship-building,Liquid service,petroleum cracking,chemical fertilizer equipment,Drawing-oil-equipment and structure purposes.
Packing: Bundles,seaworthy packing
Main Export Market: Middle East,Southeast Asia,Europe and America,South America,Africa and so on.Chemical Properties Of EN10219 Hot Rolled Steel Pipes

Number No. Grade Grade Yield point Tensile strength Ultimate longitudinal Impact strength
  elongation at bending
EN 10219 (DIN 17120) seamed structural pipes, cold-rolled from unalloyed steel
1.0039 S 235 JRH R St 37-2 2351 360-510 24 27/20º
1.0149 S 275 JOH St 44-2 2751 430-580 20 27/0º
1.0138 S 275 J2H St 44-3 N 2751 430-580 20 27/-20º
1.0547 S 355 JOH St 52-3U 3551 510-680 20 27/0º
1.0576 S 355 J2H St 52-3 N 3551 510-680 20 27/-20º
EN 10219 (DIN 59411) seamed structural pipes, cold-rolled from fine-grained steel
1.0493 S 275 NH StE 285 N 2751 370-540 24 40/-20º
1.0497 S 275 NLH T StE 285 N 2751 370-540 24 27/-50º
1.0539 S 355 NH StE 355 N 3551 470-630 22 40/-20º
1.0549 S 355 NLH T StE 355 N 3551 470-630 22 27/-50º
1.8953 S 460 NH StE 460 N 4601 550-720 17 40/-20º
1.8956 S 460 NLH T StE 460 N 4601 550-720 17 27/-50º
1.8843 S 275 MH   2751 360-510 24 40/-20º
1.8844 S 275 MLH   2751 360-510 24 27/-50º
1.8845 S 355 MH   3551 450-610 22 40/-20º
1.8846 S 355 MLH   3551 450-610 22 27/-50º
1.8847 S 420 MH   4201 500-660 19 40/-20º
1.8848 S 420 MLH   4201 500-660 19 27/-50º
1.8849 S 460 MH   4601 530-720 17 40/-20º
1.885 S 460 MLH   4601 530-720 17 27/-50º



Optional Information
- Payment : L/C T/T
- Delivery : 10 days
- Origin : China
- Minimum Order : 5 MT
- Packaging : Bundle/Bulk
- Inspection : China Commodity Inspection Bureau
- Samples : Not Avaliable
- Remarks : the length is fixed or random



Details Of EN10208 Hot-Rolled Steel Pipes(SMLS)
Manufacturer CHINA QIANCHENG STEEL PIPE CO.,LTD (QCCO)
Brand ZH
O.D. 21.3mm-965mm
W.T. 2mm-60mm
Standard ASTM,EN,BS,GB,GOST,JIS,DIN
Grade 10# 20# 45# 16Mn
A53B A106B API 5L GR.B A179 A

P195TR1,P235TR1,P265TR1,P195TR2,P235TR2,P265TR2,P245,P195GH,L290,L360,

P235GH,P265GH,S275JRH,S275J2H,S355J2H
ST10,ST20,09G2S
ST35.8,ST45,ST45.8,ST44.2,ST44.3,ST52.3,STE290,STE320,STE360
API 5L X42,X46,X52,X56,X60
Length 5.8-12m or according to customer’s demand
Usage Range

1.Structural Pipe2.Oil or Gas Transportation3.Fluid Pipe4.Line Pipe5.Drill Pipe

6.Boiler Pipe7.Other uses we can produce according to customer requirement

Chemical Details Of EN10208 Hot-Rolled Steel Pipes(SMLS)

EN10208 steel pipes

Number No. Grade Grade Yield point Tensile strength

Ultimate

longitudinal

Impact

strength

 Carbon
  elongation at bending equivalent
EN 10208-2 (DIN 17172) steel line pipes for gas and combustible media – B requirement class
1.0457 L 245 NB StE 240.7 245-440 415 22 40 0,42
1.0484 L 290 NB StE 290.7 290-440 415 21 40 0,42
1.0582 L 360 NB StE 360.7 360-510 460 20 40 0,45
1.8972 L 415 NB StE 415.7 415-565 520 18 40 w/uzg

1.8948 L 360 QB   360-510 460 20 40 0,42
1.8947 L 415 QB   415-565 520 18 40 0,43
1.8952 L 450 QB   450-570 535 18 40 0,45
1.8955 L 485 QB   485-605 570 18 46 0,45
1.8957 L 555 QB   555-675 625 18 61 w/uzg

1.0418 L 245 MB – 245-440 415 22 40 0,4
1.0429 L 290 MB StE290.7 TM 290-440 415 21 40 0,4
1.0578 L 360 MB StE360.7 TM 360-510 460 20 40 0,41
1.8973 L 415 MB StE415.7 TM 415-565 520 18 40 0,42
1.8975 L 450 MB StE445.7 TM 450-570 535 18 40 0,43
1.8977 L 485 MB StE480.7 TM 485-605 570 18 46 0,43
1.8978 L 555 MB   555-675 625 18 61 w/uzg
